Rally Bar

ALL-IN-ONE VIDEO BAR FOR MEDIUM TOrnLARGE ROOMSrn

• Logitech Rally Bar sets a new standard for video meetings in mediumrnand large rooms. Rally Bar is remarkably simple to deploy, use, andrnmanage remotely.rnPlug and play Rally Bar with any PC or laptop, or leverage its built-inrncompute and use it in appliance mode. Rally Bar works with mostrnplatforms you use to connect hybrid teams, ensuring an effortlessrnexperience from the home to the office, and everywhere in between.rnPlus, Rally Bar easily integrates with meeting controllers like TaprnIP and other devices like Sight, making it easy to build a videornconferencing experience ideal for both in-office and virtual meetingrnattendees.

EVERYONE IS SEEN AND HEARD CLEARLY

• AI video intelligence, advanced sound pickup, noise suppression, and ongoing software improvements provide a clear and natural meeting experience for remote workers.

WORKS WITH LEADING VIDEO PLATFORMS

• Rally Bar works with most platforms you use to connect hybrid teams, ensuring an effortless experience from the home to the office, and everywhere in between.

QUICK TO SET UP, EASY TO MANAGE

• Designed to deliver video meetings in medium and large rooms with ease, Rally Bar is quick to set up, simple to manage, and easy to integrate with Tap or Tap IP through CollabOS. Plus, use optional accessories on the wall, table, or display.
• Plus, use Rally Bar as a meeting room appliance, in USB mode connected to a meeting room PC, or connect via laptop

 PRODUCT SPECS & LINKS

A SERVICE PLAN FOR ALL YOUR MEETING ROOMSrn

• Ensure business continuity and simplify management with our comprehensive service plan Select. With 24/7 directrnaccess to product experts, support within an hour, and fast product replacements, we help you keep your roomsrnand Logitech solutions ready for the next meeting. Select covers Rally Bar and all other Logitech devices in thernroom under an active warranty.

MICROPHONES

• Frequency Response: 90Hz – 16kHz
• Sensitivity: >-36dBFS +/-1dB @ 1Pa
• Microphone Data Rate Output: 48 kHz
• Pickup Range: 23 ft (7 m)
• Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams
• Audio Processing: AEC (Acoustic Echo cancellation), VAD (Voice Activity Detector)
• Noise Suppression: AI filter
• Add-on Mics: Supports up to 4 additional Rally Mic Pods for larger conference rooms.

INTERFACES

• HDMI Out: 2 (up to 1080p)
• HDMI In: 1
• USB 3.0: 3x Type A, 1x Type C
• Network: 10/100/1G Ethernet
• WiFi: 802.11a/b/g/n/ac (MIMO)
• External Mic Input: Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable)
• Remote Control: Bluetooth® Low Energy

POWER & CABLES

• Power Supply: Auto-sensing
• Operating Voltage/Power: 100-240V, 19V, 4.74A
• Power Supply Dimensions: 127mm x 51mm x 30mm
• DC Cable: 1.5m / 4.9 ft
• AC Cable: 1m / 3.28 ft
• HDMI 1.4 Cable: 2m / 6.5 ft
• USB A to USB C 3.0 Cable: 2.2m / 7.2 ft

ENVIRONMENTAL

• Operating Temperature: 0 to 40 °C
• Storage Temperature: -40 to 70 °C
• Humidity: 10 to 95%
• BTU/hr: 57 idle, 64 in meeting

SECURITY

• Full Disk Encryption: AES-128
• Data Encryption: Symmetric Keys, PKI
• Device Identity: Protected by device attestation
• Device Access: Authenticated using API
• Key Protection: Arm TrustZone, RPMP

PACKAGE CONTENTS

• Rally Bar
• Power supply
• AC power cord
• HDMI cable
• USB cable
• Remote control
• Lens caps for main camera and AI Viewfinder
• User documentation
